Bulletproof safety glass BR4-NS/BR6-NS – Hammerglass

In an increasingly violent world where gunshots, terrorist attacks, vandalism and burglaries are part of everyday life, the need for modern protection products is increasing. Hammerglass ballistic protection includes unique, lightweight bullet-resistant solutions in the higher protection classes BR4-NS and BR6-NS (No Splinter), combining laminated glass panes with a Hammerglass pane to achieve the lowest possible weight and thickness . With our many years of experience and extensive knowledge, we actively develop personal protective equipment for high-risk targets in national and local authorities, in industry and commerce as well as for private individuals. Our shatterproof solutions are ideal for protecting premises where threats may occur:

Same protection – less thickness – less weight

Bulletproof or bulletproof glass is available in a variety of thicknesses depending on the level of protection desired. The Hammerglass ballistic glass solution consists of a series of glass panes laminated together with a Hammerglass film. This shatterproof solution is thinner and weighs significantly less than comparable all-glass solutions, which proves to be a great advantage in many situations – not least for sliding and pivoting doors.

An all-glass BR6 NS glazing solution is 63mm thick and weighs almost 160kg/m². The use of Hammerglass in the pack reduces the thickness to 39mm and the weight to 90kg/m². The incorporation of Hammerglass in bulletproof, reinforced stainless steel partitions (security classes FB4 and FB6, EN 1522) offers complete protection against ballistic attacks. Ballistic resistance refers to both the glass and the associated frame.

Classification of bulletproof glass

Bullet-resistant glass is certified according to the European standard EN 1063. The different levels of protection are indicated by the classes BR1 to BR7, where BR1 is the lowest and BR7 is the highest protection class. The most common protection classes are BR4 and BR6. Hammerglass ballistic glass solutions have been tested by the Beschussamt Ulm in Germany and are certified as compliant with protection classes BR4-NS and BR6-NS.

Let us advise you on the planning

Feel free to contact us in the first planning phase! We offer you complete solutions with tailor-made ballistic steel systems for window and door applications – a comprehensive turnkey solution including confidential risk analysis and security needs assessment. Ballistic glass is not a stock item, but is made to order and made to measure. This means that you should expect a delivery time of around 8 weeks.

Zusätzliche Informationen

Zusätzliche Informationen zum Produkt Beschuss-sicheres Glas BR4-NS/BR6-NS – Hammerglass

LieferantHammerglass AB

CLASS CHARGE DISTANCE PRESSURE Pso
IMPULSE Iso
HMG PRODUCT
EXR1 3 kg 5 m 0,75 bar 1,05 bar/ms HmG 12 mm
EXR2 3 kg 3 m 2,3 bar 1,65 bar/ms HmG 12 mm
EXR3 12 kg 5,5 m 1,7 bar 2,25 bar/ms
EXR4 12 kg 4 m 3,6 bar 3,00 bar/ms
EXR5 20 kg 4 m 6,3 bar 4,20 bar/ms

Zertifizierungen: Link BlogeintragWiki Hammerglass Zertifizierungen
